Tailoring Grinding Solutions for the Unique Challenges of Aerospace

In aerospace manufacturing, precision grinding is essential for producing components that must reliably perform under extreme conditions. Whether it’s turbine blades, vanes, or structural parts, these components require tight tolerances, exceptional surface finishes, and consistent performance—all while being made from some of the most challenging materials to grind, such as nickel-based superalloys, titanium, and ceramic matrix composites (CMCs).

The grinding process must balance aggressive material removal, heat management, and tool wear resistance to achieve the required part quality and efficiency. This is where electroplated grinding wheels and diamond rotary dressers provide significant advantages, offering solutions to some of the most persistent challenges in aerospace grinding.

Evolving Challenges in Aerospace Manufacturing

Aerospace manufacturers are continuously refining their production processes to meet increasing performance demands. Several industry trends are shaping the way grinding solutions must adapt:

• Advanced Materials Require New Machining Strategies

  The use of lightweight, high-strength materials such as carbon fiber composites, aluminum-lithium alloys, and CMCs is growing. These materials improve fuel efficiency without sacrificing structural integrity. However, their brittleness, heat sensitivity, and abrasiveness present machining challenges that require specialized grinding technology to shape them.

• Additive Manufacturing Is Changing Component Design

  3D-printed aerospace parts often require post-processing to achieve dimensional accuracy and surface integrity. Superabrasive grinding wheels are particularly well-suited for refining these components without inducing stress or altering their properties.

• Rising Demand for High-Precision Parts

  Increasing global defense spending and increased commercial air travel require manufacturers to produce high-performance components at scale, making efficient and repeatable grinding solutions more critical than ever.

• Space Exploration Is Pushing Material Science Forward

  New materials developed for satellite technology and space vehicles require grinding solutions that can maintain precision while working with ultra-hard alloys and ceramics, materials designed to withstand the extreme conditions of space.

With these challenges in mind, engineering the right grinding wheel is more critical than ever for ensuring part quality, process efficiency, and long-term performance in aerospace applications.

The Role of Electroplated Grinding Wheels in Aerospace

Electroplated grinding wheels offer a unique advantage in aerospace manufacturing due to their single-layer abrasive structure, aggressive cutting action, and ability to maintain form without dressing. Unlike bonded grinding wheels, where abrasive grains are embedded within a matrix, electroplated wheels expose a full layer of diamond or cBN material, ensuring sharp cutting edges and consistent performance.

How Electroplated Grinding Wheels Address Aerospace Challenges

✔ Maintaining Profile Accuracy: Electroplated wheels hold complex geometries without needing dressing, making them ideal for intricate aerospace components.

✔ High Stock Removal with Minimal Heat Generation: The open structure of electroplated wheels allows for aggressive material removal while features like coolant slots and through the wheel coolant delivery can be added to reduce heat buildup—critical when working with heat-sensitive materials like titanium.

✔ Custom-Engineered for the Application and Material: Abrasive size and type, core accuracy, and uniform plating are all critical to match unique aerospace grinding requirements.

✔ Longer Tool Life, Less Downtime: Electroplated wheels maintain their shape throughout their lifespan, eliminating the need for dressing and reducing machine downtime.

✔ Cost Savings with Strip and Replate Services: CDT offers a customized strip and replate program that allow customers to reuse the same core, reducing costs and lead times while delivering the same high-level performance. Our strip technology safely removes remaining abrasive without damaging the core and returns the tool to “like new” condition after replating. This makes it a more cost-effective and sustainable solution for aerospace manufacturers running frequent grinding operations.

"Electroplated grinding wheels are a great fit for aerospace because they are both precise and efficient. They hold intricate profiles, handle high speeds, and stand up against tough materials like nickel alloys, titanium, and ceramics — plus, with our strip and replate services, customers can extend the life of their tools and keep costs down without sacrificing performance," says Jordan Donnelly, CDT Product Line Manager for Electroplated Products.

Optimizing Grinding Performance with Diamond Rotary Dressers

Precision grinding requires continuous wheel maintenance to ensure optimal cutting efficiency and part consistency. Diamond rotary dressers are essential in aerospace manufacturing for truing and conditioning grinding wheels, ensuring the reliability and accuracy of the grinding process.

Key Benefits of Diamond Rotary Dressers in Aerospace

✔ Consistency Across High-Volume Production: Rotary dressers keep grinding wheels performing uniformly, ensuring part consistency and accuracy from the first to the last component.

✔ Reducing Cycle Times & Increasing Efficiency: Keeping wheels properly conditioned and sharp, minimizes grinding forces and allows for optimum cycle times while maintaining part quality.

✔ Application-Specific Design: Whether the application requires traverse or plunge-style dressing, CDT custom-designs each rotary dresser to specific customer needs and applications.

✔ Manufacturing Customization: Every application is different, thus requiring different solutions. CDT solves this issue by offering sintered, reverseplated, and metal bonded rotary dressers.

"Consistency is everything in aerospace manufacturing. Even the smallest deviation can throw off performance, which is why rotary dressing is so important. Our custom-engineered dressers keep grinding wheels precise and reliable, helping manufacturers get accurate, repeatable results every time," explains Troy Giacherio, CDT Product Line Manager for Diamond Rotary Dressers.

The Advantage of a Multi-Disciplinary Grinding Expertise

While electroplated grinding wheels and diamond rotary dressers provide high-performance solutions, CDT’s expertise extends beyond these technologies—allowing us to approach aerospace grinding challenges from multiple angles.

We have extensive experience working with a variety of:

• Bond Types: Plated, resin bond, metal bond, vitrified bond, hybrid bond

• Core Materials: Carbon fiber, ceramic, high-tensile strength steel, and many more

• Diamond Patterns: Handset, random set, reverse plated, CVD-reinforced

• Abrasives: Diamond, cBN, and conventional abrasive grinding solutions

This broad expertise enables CDT to study materials, test performance, and develop tailored grinding solutions that push the boundaries of what’s possible. Our dedicated grinding lab allows us to simulate real-world aerospace applications, testing how new materials react during grinding and refining wheel designs to optimize performance.

This cross-industry experience from both the product and application side fosters innovation, ensuring that we don’t just provide grinding wheels—we provide solutions tailored to the specific needs of aerospace manufacturers.

Expanding Capabilities to Better SERVE the Aerospace Industry

To address increasing global demand for aerospace products, CDT is expanding its electroplated grinding wheel production capacity with a new building that will grow its second plating line in Europe. This expansion will increase production efficiency, reduce lead times, and allow CDT to serve aerospace manufacturers at a larger scale.

"Expanding our plating facility is a big step forward. With the new electroplating line, we can speed up production and handle more capacity, getting products delivered faster. It’s all part of CDT’s commitment to innovation and supporting the growing needs of our aerospace customers," says Justin Hughes, Production Manager at CDT Ltd.

Finding the Right Grinding SolutionS for Aerospace Manufacturing

The challenges of aerospace manufacturing—tough materials, tight tolerances, and growing demand—require advanced grinding solutions that can maintain precision, minimize downtime, and innovate at speed and scale.

With specialized knowledge in electroplated diamond and cBN grinding wheels, advanced diamond rotary dresser technology, and expertise across many other grinding product types, CDT is uniquely positioned to help aerospace manufacturers optimize production processes and innovate for the future.

Contact us today to discuss how CDT’s precision grinding solutions can help optimize your aerospace manufacturing process.

Core Matters: How Different Wheel Body Materials Impact Grinding

When using superabrasive grinding wheels in precision manufacturing, selecting the right abrasive, bond type, and wheel core material is critical for optimal grinding performance and wheel life. While abrasives and bond types often take center stage, the wheel core can be equally important. The core material is the foundation that provides structural support and stability. The right core material ensures high performance while preventing machine strain, excessive grinding wheel wear, and unnecessary cost. But how do you determine the best core material for your specific needs?

In Episode 10 of The Grinding Chronicles, CDT Engineering Manager Jeff Wirth breaks down the essential properties of core materials and how they influence grinding applications. Watch the video or read the article below to learn how to choose the best option for your application.

The Grinding Chronicles - Episode 10

Selecting the Right Core Material for Grinding Wheels

The core of a superabrasive grinding wheel does more than just hold the abrasive—it directly impacts machine efficiency, grinding precision, and tool longevity. Choosing the right core material not only optimizes performance but also helps prevent unnecessary damage to the wheel, machine, and workpiece while enhancing operator safety.

Common core materials for superabrasive grinding wheels include metals—such as steel, aluminum, and copper—as well as non-metals like ceramics and resin composites. Ceramic or vitrified cores are commonly found in conventional abrasive grinding wheels and are also used in some superabrasive grinding wheels. Resin composite cores may be made from materials like bakelite, abrasive composites, or carbon fiber. Each of these materials has unique properties that affect grinding performance, and understanding their characteristics helps manufacturers make more informed decisions.

Understanding Core Material Properties

Density – Defined as mass per unit volume, density directly affects the weight of a grinding wheel. Heavier cores put added stress on machines and spindle bearings, which is why large-diameter grinding wheels are often designed with lighter core materials like carbon fiber, bakelite, or ceramic. An overly heavy wheel can reduce machine longevity, increase energy consumption, and pose handling risks for operators, making weight an important consideration for both performance and safety.

Expansion – Core materials expand due to heat and mechanical forces, which can impact grinding accuracy. Minimizing expansion is crucial for applications with tight tolerances, as it helps prevent wheel distortion and ensures consistent precision. Expansion occurs in two forms:

• Mechanical Expansion: At high speeds, some core materials naturally expand due to centrifugal forces. Materials with high tensile strength resist this growth, maintaining stability and accuracy over time.

• Thermal Expansion: Heat generated during grinding can cause materials to expand, leading to dimensional changes and reduced precision. Materials with low thermal expansion coefficients are essential for consistently achieving tight tolerances.

For high-speed and high-precision grinding applications, grinding wheels with cores made from high-tensile steel, carbon fiber, or vitrified ceramic often perform better. These materials minimize mechanical and/or thermal expansion, ensuring consistent performance, reduced deformation, and greater accuracy under extreme conditions.

Thermal Conductivity – This property determines how well a core material dissipates heat. Efficient heat transfer prevents thermal damage (burning) to the workpiece, improves surface quality, and extends tool life. Metal materials like Copper and Aluminum with high thermal conductivity remove heat, leading to lower wear and improved performance in high heat applications such as fluting drills.

Modulus of Elasticity (MOE) – This measurement indicates a material’s ability to resist deformation under stress. A higher MOE means the material is stiffer and less likely to flex or deform. Steel has a very high MOE. This can be beneficial for applications with high grinding forces that require tight tolerances, as a flexible core can introduce inconsistencies in grinding performance.

Comparing Core Materials: Strengths and Weaknesses

Each core material offers specific advantages and drawbacks. Here’s how some of the most common materials compare:

• Steel is strong, durable, and resistant to mechanical expansion. However, its heavy weight can strain machinery.

• Aluminum is lighter and often more affordable than steel, with higher thermal conductivity and resistance to corrosion. However, it has significantly higher thermal expansion compared to steel and other materials.

• Copper offers excellent thermal conductivity and a high modulus of elasticity (MOE), but its weight and cost make it less suitable for large grinding wheels.

• Ceramic is lightweight, cost-effective, and resistant to expansion, but low thermal conductivity and high stiffness or brittleness can be a drawback.

• Resin composites, including bakelite, are affordable and lightweight. However, they lack stiffness and high thermal conductivity, making them more susceptible to expansion and heat buildup in high-force grinding applications.

• Carbon fiber is ideal for demanding applications due to its high stiffness and low weight. However, it tends to trap heat and is more expensive than other materials.

Choosing the Right Core Material for Your Application

Selecting the best core material depends on several factors, including the type of grinding being performed, the machine’s limitations, and cost considerations. For example:

• Flute grinding and medical drill bits operate at traditional speeds with lower grinding forces. This means that a wide variety of core materials can be used without significant performance issues. In these cases, ceramic cores are often recommended because they provide an excellent balance of cost and functionality.

• High-speed applications like camshaft grinding generate significant heat and grinding forces. This makes high-stiffness materials like carbon fiber or high-tensile steel essential to be able to perform effectively and safely.

• Hybrid or combination cores are an innovative solution for balancing weight, stiffness, and cost. This approach involves layering or combining different materials to optimize performance while keeping costs manageable. For instance, a steel core can be reinforced with carbon fiber to reduce weight without sacrificing strength.

Practical Considerations in Core Material Selection

Beyond material properties, cost plays a major role in selecting the right core material for grinding wheels. While core materials like carbon fiber and vitrified ceramic are both resistant to mechanical and thermal expansion and lighter weight, they come at very different price points. Once all process requirements are met, cost is usually the deciding factor, as manufacturers balance performance needs with material costs to avoid unnecessary expenses.

Budget-Friendly Options – Ceramic and resin composites provide cost-effective solutions for applications with lower grinding forces and minimal heat generation. These materials perform well in traditional grinding operations without adding unnecessary expense.

Mid-Range Solutions – Aluminum and standard steel cores offer a balance between affordability and durability. These materials are commonly used in medium-duty grinding applications where moderate strength and thermal properties are required, optimizing cost per part without sacrificing performance.

Premium Core Materials – High-tensile steel and carbon fiber provide top-tier performance, making them ideal for high-speed and high-force applications. While their higher price point increases the initial cost of the grinding wheel, their longevity and reliability often justify the investment by reducing long-term cost per part through extended tool life and efficiency gains.

When selecting a core material, it is essential to consider not just the upfront cost but also long-term savings from reduced machine wear, improved grinding efficiency, and longer tool life. CDT’s engineering team can help assess cost-effectiveness based on your specific grinding application, ensuring the best balance between performance and cost per part.

Optimize Your Grinding Wheel Performance with CDT

Choosing the right core material is critical for achieving consistent, high-performance grinding results. Whether you're working with grinding applications for heavy-duty industrial engine components or high-precision medical tool manufacturing, the engineering team at Continental Diamond Tool is ready to assist in customizing a grinding wheel with the materials that are best for your needs.

If you have questions about selecting the best core material for your specific application, CDT’s engineers are here to help. Reach out to TheGrindingChronicles@cdtusa.net for expert advice.

---

Check out more videos from The Grinding Chronicles and follow CDT on Linked In for the latest news in grinding technology.

The Essential Role of Diamond Grinding Wheels in Manufacturing with Composite Materials

Manufacturing with composite materials presents unique challenges: differences in hardness, fiber pullout, and heat sensitivity require grinding wheels with specialized engineering to prevent defects and ensure tool longevity. Superabrasive grinding wheels, particularly those utilizing diamond abrasives, have become indispensable tools in achieving the desired quality and efficient grinding of parts made from composites.

Understanding Composites

Composites are engineered materials made by combining two or more constituent materials with distinct physical or chemical properties. The result is a material that exhibits characteristics different from the individual components, often offering enhanced strength and reduced weight. Common types of composites include:

• Fiberglass: Comprising glass fibers embedded in a resin matrix, fiberglass is renowned for its versatility and is used across many sectors, from automotive components to sporting goods to garage doors.

• Ceramic Matrix Composites (CMCs): These consist of ceramic fibers within a ceramic matrix, providing high-temperature stability and strength. CMCs are ideal for many aerospace applications.

• Fiber Matrix Composites (FMCs): Combining fibers such as carbon or aramid with a polymer matrix, FMCs are commonly used in wind turbines and marine vessels due to their excellent strength-to-weight ratios.

The Role of Superabrasive Grinding Wheels

Manufacturing with composites presents unique challenges, primarily due to their heterogeneous nature and the abrasive characteristics of reinforcing fibers. Superabrasive grinding wheels, especially those with diamond abrasives, can be custom engineered to address these challenges effectively.

Fiberglass and FMCs: For these materials, electroplated diamond grinding wheels are an excellent choice. Plated diamond grinding wheels are widely used because they can be designed with an open structure that helps prevent issues like "loading," where softer materials can clog the wheel and lead to inefficiencies. These wheels are often employed with aggressive grit sizes ranging from 40 to 120 to ensure efficient material removal and desired surface finishes.

"Each composite material presents unique machining challenges. For example, Fiberglass and Fiber Matrix Composites can be tricky because they tend to ‘string’ if not cut properly. That’s why we often recommend a plated grinding wheel with aggressive grit—it keeps the material from gumming up and ensures a clean finish,” says Matt Harnish, CDT Sales Rep for Diamond and CBN Plated Products.

CMCs: Given their hardness and brittleness, CMCs require a more nuanced approach. While plated grinding wheels are suitable for the majority of composite grinding applications, approximately 75% of those we see at CDT, certain scenarios may benefit from metal bond or hybrid bond grinding wheels.

"Plated wheels are ideal for most composite applications because they maintain their profile and cut aggressively without excessive wear. But for Ceramic Matrix Composites, we sometimes refer customers to our metal bond or hybrid bond product lines when deeper diamond layers are needed for longevity and performance,” says Jordan Donnelly, Plated Product Line Manager.

Maintenance and Performance Considerations

Due to the variable composition in composite materials, it is common for grinding wheels to experience "loading," where debris accumulates on the wheel's surface and diminishes cutting efficiency. While plated grinding wheels typically do not require dressing, in these applications some dressing can help to restore their optimal performance and prolong their lifespan. Proper coolant application can also help to reduce the amount of debris.

"One of the biggest factors in machining composites is managing tool wear. If a wheel starts loading up, it’s not cutting efficiently. Regular dressing keeps the wheel sharp and extends its life, ensuring our customers get consistent performance,” Matt explains.

Comparative Advantages

When evaluating grinding solutions for composites, several factors come into play:

• Performance: Superabrasive grinding wheels, particularly diamond-based plated wheels, offer superior cutting efficiency and precision compared to alternatives like carbide-tipped wheels.

• Durability: The inherent hardness of diamond ensures a longer tool life, reducing the frequency of replacements and downtime.

• Cost-Effectiveness: While the initial investment in superabrasive wheels is high, their extended lifespan and enhanced performance lead to cost savings over time, often making them more cost effective when considering cost per part.

“We switched from carbide to diamond-plated wheels over 30 years ago and have seen great results. They last much longer and aren’t that much more expensive. The savings in tool life and less downtime easily make up for the cost. Diamond’s extreme hardness, durability, and efficiency make it the best choice for grinding composites, especially with the precision we need for large-scale building construction and remodel projects,” says a longtime CDT customer.

Emerging Technologies and Industry Outlook for Composite Machining

The composite industry is continually evolving, with advancements aimed at improving manufacturing efficiency and material performance. Notable emerging technologies include:

• Automated Fiber Placement (AFP): This advanced method involves the precise placement of fiber tapes onto molds, enhancing production rates and consistency in composite part fabrication.

• Additive Manufacturing with Composites: The integration of 3D printing technologies allows for the creation of complex composite structures, offering design flexibility and potential material savings.

The composites industry is experiencing robust growth, with a market valuation of $99.52 billion in 2023. This trend underscores the increasing adoption of composite materials across various sectors, driven by their advantageous properties and the continuous advancements in manufacturing technologies.

CDT is well-positioned to meet the rising demand with its state-of-the-art 500-tank plating lab in the United States. We can deliver high-capacity production of high-quality, reliable superabrasive tools. Additionally, with a larger plating facility currently being built in the United Kingdom, CDT is expanding its reach to better serve the global composites market with cutting-edge grinding solutions.

In conclusion, superabrasive grinding wheels play a pivotal role in the machining and fabrication of composite materials. Their ability to deliver precision, efficiency, and longevity makes them indispensable in the ever-evolving landscape of composite manufacturing. The use of composite materials is growing, and CDT is ready. Call us today to discuss how our precision grinding solutions can enhance your production process.

Celebrating Our Apprentices

CDT Ltd.'s current and former interns (left to right): Corey Lloyd-Jones, Joe Bowles, Stephanie Hughes-Jones, Daniel Hughes-Jones, and Rhys Butler.

Investing in the Future: Celebrating Our Apprentices for National Apprenticeship Week

At Continental Diamond Tool (CDT), we take great pride in nurturing the next generation of engineers through our apprenticeship programs. In celebration of National Apprenticeship Week in the U.K., we’re highlighting the inspiring journeys of five apprentices at our manufacturing center in Wales. Read on to see how these talented individuals have developed their skills, grown within the company, and are shaping the future of engineering.e.”

From Apprentice to Supervisor – Joe Bowles’ Journey

Joe Bowles began his career with Continental Diamond Tool Ltd. in September 2007 as an engineering apprentice. Over the years, his dedication and willingness to learn saw him progress into new roles, gaining invaluable experience along the way. Today, he is the Supervisor of the Grinding Department, where he leads a skilled team and ensures high standards of quality and precision.

Reflecting on his journey, Joe shares:

"From an apprentice 17 years ago to a supervisor, my path has been driven by hard work and the support of a company that values growth, innovation, and investment in people. I look forward to furthering my career with CDT and being part of its bright future."

Joe’s success is a testament to the long-term benefits of apprenticeships, illustrating how they can open doors to leadership and career progression.

---

Daniel Hughes-Jones – A Key Player in CNC Machining

Daniel joined CDT Ltd. in March 2021, quickly making an impact in the CNC Machining Department. He successfully completed his HNC in Engineering, further strengthening his knowledge and technical expertise. Now, as a key team member, he operates multiple CNC machines and plays an important role in training new apprentices.

"My apprenticeship at CDT provided me with vital knowledge and a developed skill set, and I’m grateful to pass on my knowledge and experiences to the next generation of apprentices." – Daniel Hughes-Jones

Daniel’s ability to mentor new apprentices showcases the value of experienced employees sharing their knowledge, ensuring a strong and skilled workforce for the future.

---

Corey Lloyd Jones – Building a Strong Foundation

Corey started his apprenticeship with CDT Ltd. in September 2023 and is currently in his second year, working towards his HNC in General Engineering while also completing a Level 3 NVQ. With a strong ambition to learn, Corey is eager to develop his expertise across multiple machines and broaden his engineering knowledge.

"After finishing my apprenticeship, I would like to progress further within the company and learn more skills on more machines. I chose this career path as it looked like a good challenge. I am doing the general engineering HNC course because it opens up a lot of opportunities for me in the future, rather than having just mechanical or electrical HNC." – Corey Lloyd Jones

Corey’s enthusiasm for engineering showcases how apprenticeships provide a solid foundation for career growth, allowing young professionals to tailor their learning to suit their ambitions.

---

Rhys Butler & Stephanie Hughes-Jones – The Next Generation of Engineers

Rhys Butler and Stephanie Hughes-Jones, Daniel’s younger sister, are the newest members of CDT Ltd.’s apprenticeship program, having joined in September 2024. Though early in their careers, both are already embracing the challenges and opportunities that come with learning on the job.

Rhys shares his thoughts on his apprenticeship so far:

"I've been on my apprenticeship for around seven months now, and I've thoroughly enjoyed it because it has provided hands-on experience, and a deeper understanding of how complex systems come together. The opportunity to apply theoretical knowledge in real-world settings has been both challenging and rewarding. I've gained valuable skills in problem-solving, teamwork, and technical expertise, which have made me more confident in my abilities. Looking ahead, I would love to further develop my expertise in engineering and continue to grow in a role where I can contribute to impactful projects." – Rhys Butler

Stephanie, who was drawn to engineering for its balance of hands-on work and intellectual challenge, shares her experience:

"I chose engineering because I like jobs that are both physically challenging and mentally interesting. My apprenticeship helps me improve my skills as a machinist while giving me chances to keep learning and growing." – Stephanie Hughes-Jones

Their journeys emphasize how apprenticeships provide real-world experience, technical expertise, and career-building opportunities from day one.

---

Apprenticeships are more than just training—they’re a launchpad for a successful career. They provide a solid foundation for career progression, hands-on experience, and the opportunity to develop vital skills in a fast-paced, innovative environment.

The apprentices above are prime examples of what can be achieved through dedication, hard work, and the right support. From those just starting out to those who have grown into leadership roles, their journeys highlight the value of apprenticeships and the opportunities they create.

👉 Interested in an apprenticeship or know someone who is? CDT Ltd. works closely with Coleg Llandrillo to identify promising candidates for our highly competitive engineering apprenticeship programme. Each year, we offer placements to 2 to 3 students. The next apprenticeships will begin in September 2025. If you’re interested, we encourage you to explore Coleg Llandrillo’s Engineering Programme as the best route to be considered for a future opportunity with us. Learn more about Coleg Llandrillo here: https://www.gllm.ac.uk/

---

Continental Diamond Tool Limited (CDT Ltd.), based in Kinmel Bay, Rhyl, U.K., is the European subsidiary of Continental Diamond Tool Corporation, headquartered in New Haven, Indiana, U.S.A. For more than 40 years, CDT Ltd. has been a leader in diamond rotary dresser technology, originally operating as Consort Precision Diamond. Since joining CDT, the company has expanded its product line, delivering high-performance diamond plated grinding wheels and other premium superabrasive products to customers worldwide.

---

CDT’s Lab Evaluates Blaser Coolants in Flute Grinding Applications

At Continental Diamond Tool (CDT), we pride ourselves on pushing the limits of grinding technology. In one recent trial, The Grinding Chronicles team has partnered with Blaser Swisslube to test the performance of different coolants on our EVO hybrid bond grinding wheels. This experiment in CDT’s grinding lab aims to determine which coolant best enhances cutting performance, tool life, and workpiece quality in precision flute grinding applications.

Parameters for Success

Leading this effort is CDT Application Engineer Harrison Sheldon and CDT Engineering Consultant Jon VanSant, who are testing three different Blaser fluids under controlled conditions. They are measuring key parameters such as power, force, and grinding wheel wear while closely inspecting the visual quality of the workpiece for signs of burn or other surface finish issues.

“Our focus is on how the grinding wheel cuts, wears, and the resulting workpiece quality,” Jon explains. “By measuring parameters like power and force, we aim to collect data that can objectively compare the performance of each coolant under consistent conditions.”

Three representatives from Blaser joined Harrison and Jon last week at CDT’s lab: Senior Application Engineer Brett Reynolds from the New York plant, and Grinding Business Development Managers Tom Cappadona, also from New York, and Simon Stalder, representing Blaser’s headquarters in Switzerland. For this trial, Blaser has provided the coolant fluids, while CDT is supplying the EVO hybrid bond grinding wheels and the data collection equipment in the grinding lab. This setup ensures a comprehensive, scientific approach to analyzing performance with these coolants.

“When Tom approached us about this trial, we saw an opportunity to try something new with the equipment in our grinding lab,” says Harrison. “We’re excited to see how each formula stacks up to help the team at Blaser guide their customers in optimizing their process.”

Simon Stalder expressed his enthusiasm for the trial results, eager to share the findings with his engineering team in Switzerland. These results will provide valuable insights into how Blaser’s latest coolant technology enhances grinding performance and efficiency. As a global leader in metalworking fluids, Blaser delivers tailored formulas for every material, industry, and application.

Benefits of a Dynamic Testing Environment

The dynamic testing environment in CDT's grinding lab allows Harrison and Jon to adjust parameters on the fly, testing variables such as feed rate while maintaining consistent wheel speed. This enables them to evaluate the optimal feed rate range for each coolant type.

“One key advantage of running trials in the lab is the ability to collect objective data in controlled conditions,” says Jon. “Unlike in the field, where varied operator techniques can affect outcomes, our lab setting allows us to isolate variables and focus on actionable insights.”

While Blaser has come to CDT's lab primarily for the technical instrumentation and grinding know-how of our team, customers do not have to travel to take advantage of the lab’s capabilities. “CDT’s grinding lab is exceptionally flexible due to its portability. We frequently gather data directly from our customers’ processes by installing equipment at their site and analyzing it in our lab,” Harrison notes, “or we can simulate their operations on our machines and collaborate remotely to tweak their process.”

The expertise of Blaser’s application engineer, Brett Reynolds, has also been instrumental in these trials. “Brett brings a deep understanding of Blaser’s fluid formulation and their customer applications, which complements our grinding expertise,” adds Jon.

Trials on the Walter Helitronic Machine

As a 5-axis tool and cutter grinder, the Walter Helitronic is a purpose-built machine that is a centerpiece in CDT’s grinding lab and perfect for trials like this. Its versatility and precision are critical for evaluating different grinding configurations.

“The Walter machine is capable of thousands of functions, but it’s most commonly used for round cutting tools, making it perfect for flute grinding trials with our EVO Hybrid Bond fluting wheels,” Harrison says. “Its high precision, repeatability, and compatibility with advanced cooling systems make it the ideal platform for these tests.”

Jon elaborates, “The Walter allows us to make real-time adjustments to speed, feed rate, and pressure, which is essential for testing performance during these trials. Its automation and sensitive readings ensure accurate, repeatable results.”

The team at Blaser is currently reviewing the data gathered from last week’s trial and discussing how to incorporate the insights into future marketing and product development.

Accessing Our Grinding Lab Services

At CDT, we believe in the importance of real-world testing to optimize grinding processes and improve part quality. Our grinding lab is available for trials like these, whether you’re testing new grinding wheels or assessing some other metric of performance.

“Our team’s diverse areas of expertise ensures we can accommodate unique customer needs,” Harrison shares. “Whether it’s conducting tests in our lab or traveling to your site, we provide valuable solutions tailored to each challenge.”

If you’re interested in running a grinding trial with CDT, contact us with details about your process. We can recreate it in our lab or connect at your facility to gather data. From there, we develop testing parameters, share results, and make tailored recommendations for specific tools and production settings.

---

Learn more about Blaser Swisslube at:

Blaser.com

Linkedin.com/company/blaser-swisslube

Facebook.com/blaserswisslube

Instagram.com/blaserswisslube

Youtube.com/user/blaserswisslube1

Global Growth and Local Jobs Spurred by Cutting Edge Investments at Kinmel Bay Facility

Cllr Nigel Smith (left), Conwy Council’s Cabinet Member for Sustainable Economy, visits with Production Manager Justin Hughes (right), showcasing one of the precision-engineered tools made possible by our new cutting-edge equipment, funded in part by the UK Shared Prosperity Fund secured with the help of Conwy Council.

A precision engineering company in North Wales is gearing up for global growth by investing £250,000 in cutting edge equipment.

Recruitment is also underway at Continental Diamond Tool (CDT) in Kinmel Bay as part of an ambitious expansion plan that will create 40 new jobs.

It’s all preparation for a move next year to a 30,000 sq ft factory nearby that’s three times the size of the current premises on the Tir Llwyd Industrial Estate.

Overall, the firm’s Indiana-based American owners, who took it over six years ago, are pumping £4 million into the company to triple production capacity and start making new products.

The niche company specialises in the manufacture of diamond-encrusted rotary dressers and grinding wheels, with tolerances of down to 1,000th of a millimetre in terms of accuracy.

It’s one of only two similar outfits in the UK and supplies a range of manufacturing sectors, including aerospace, automotive, medical and semi-conductors.

The company’s customers include blue chip corporations like Rolls Royce and Tenneco, with more than 60 per cent of the products being exported.

According to the loyal workforce, the investment is the “perfect present” for the company that’s celebrating its 40th anniversary this year.

It was also music to the ears of Cllr Nigel Smith, Conwy Council’s cabinet member for Sustainable Economy, who is one of three councillors who represent Kinmel Bay on the authority.

The council helped CDT secure £100,000 in funding from the UK Shared Prosperity Fund towards the cost of the new equipment.

He came on a visit to see how the money had been spent on “space age kit”, including a  high tech machinery centre, lathe and inspection equipment.

Cllr Smith said: “What they do is very impressive, both in terms of the state-of-the-art technology and the high skill employment they provide in Kinmel Bay.

“It’s fantastic that they’re selling their world-leading products to an international market and they have a raft of blue chip customers like Rolls Royce.

“Over the years there has been a good relationship between the company and the council’s business development team and long may that continue.

“We were delighted to be able to help in securing £100,000 towards the cost of these cutting edge machines.

“It’s impressive, top-of-the-range technology and the level of precision they work to is mind-boggling – their tolerances are within microns. It’s engineering of the highest pinnacle.

“With them moving now to larger premises, I’ll be speaking to our team if there is anything more we can do to help them moving forward to help them grow and expand.

“Employment is a key issue in Conwy so have foster and support business where we can to retain our young people.

“It’s good to see the emphasis on training here and the apprenticeships, helped by the fact that they have a very good relationship with the local college.

“It’s always been a great company and there is now a new momentum under the American ownership and it’s very pleasing to see them invest in Kinmel Bay and that will pay dividends.

“The excellent legacy of the original company is now being turbo-charged by the Americans.

“It’s a company with ambition and it’s plain to see how committed the team are here – everybody has a good work ethic and it bodes very well for the future.”

Cllr Smith’s visit was hosted by Production Manager Justin Hughes, whose father was one of the founders of the original company, Peter Hughes.

Justin said: “In this latest investment we have spent £250,000 on the three machines and it’s well in excess of £1 million just on new equipment in the last two or three years.

“We’re very grateful to Conwy Council for their help in facilitating the £100,000 that’s come from the UK Shared Prosperity fund. It’s made a massive difference because it enables us to employ the people to use those machines.

“The skill required by the people we have to do that is of the highest order and is just as important as the machine.

“Training and developing those people is just as key as our processes and our high precision machinery so working with the engineering centre at the local college is a big help.

“I am immensely proud of the company’s legacy and the way things are moving forward. It’s in my blood, this company.

“These are really exciting times with the move to the larger premises which will enable us to have new product lines.

“Continental Diamond Tool are the third biggest superabrasives supplier in the USA and they are looking to become the biggest.

“The American side of the business is growing at a rate of 30 per cent a year and we are the European arm and they are looking to us to emulate that success over here.

“We are developing a name for ourselves against the big multi-national household names and we are becoming one of those names.

Finance Manager Michaela Lawton added: “The expansion into the new premises will enable us to increase capacity and the number of products we make so the sky is the limit.

“All this is happening in the year we are celebrating our 40th anniversary and the American side of the company is celebrating its 50th.

“We’ve got a great team of people here and there’s a shared pride in what we’re achieving.

“The expansion will create another 40 jobs and we have started to recruit people because of the skill sets required and the time it takes to train them.

“We’ve had a steady number of new employees joining us, particularly over the last four or five months so we can get all our ducks in a row.

“We make our products to 1,000th of a millimetre in terms of accuracy so we have to conduct the whole operation with the same level of exceptional quality.”

---

Related articles:

https://www.herald.wales/north-wales/conwy/global-growth-will-take-off-with-cutting-edge-kit-helping-to-create-new-40-jobs/

https://www.rhyljournal.co.uk/news/24752773.north-wales-firm-create-40-jobs-part-expansion/

https://www.insidermedia.com/news/wales/engineering-firm-targets-global-growth-with-investment-in-new-equipment-customers-include-rolls-royce-and-tenneco

https://www.baysideradio.co.uk/news/global-growth-will-take-off-with-kit-helping-to-create-40-jobs-9750

https://north-wales-business.co.uk/global-growth-will-take-off-with-cutting-edge-kit-helping-to-create-new-40-jobs/

https://businessnewswales.com/engineering-firm-invests-in-expansion-plan-and-creates-new-40-jobs/

https://www.welshnewsextra.com/global-growth-will-take-off-with-cutting-edge-kit-helping-to-create-new-40-jobs/

---

Quality Assurance at Continental Diamond Tool

At Continental Diamond Tool (CDT), quality is more than a department—it’s the cornerstone of our commitment to customer satisfaction. The quality control process at CDT is thorough, involving more than a dozen checkpoints from pre-production to the final inspection, ensuring that every tool we deliver meets our strict standards for accuracy and durability. This dedication to quality is achieved through structured quality checks and the expertise of our team, who are driven to exceed customer expectations at every stage.

A Rigorous, Multi-Stage Quality Control Process

Every tool manufactured at CDT goes through a comprehensive quality control process that spans pre-production, in-line, and final inspections. These checkpoints serve as crucial layers of verification, allowing CDT to consistently exceed industry standards for tolerance and customer expectations.

1. Pre-Production Inspections
   Quality assurance starts before any production begins. It kicks off in pre-production where we verify that the quality of the raw materials and components meet our exacting quality standards. It also takes place in our engineering department where we examine prototypes, samples, and drawings to confirm that our specifications align with the intended design. By identifying potential issues early, CDT reduces the chance of mishaps later in the production process.

2. In-Line Product Inspections
   Quality control ramps up once production starts. Production technicians at every stage are trained on in-line or in-process inspections to make sure the tool matches the customer’s specifications. This proactive inspection phase helps prevent errors and catches any inconsistencies before they compound through the production process.

3. Final Inspections
   The final inspection is the most familiar phase to many, taking place once production is complete. Every finished tool is thoroughly inspected to ensure it meets CDT’s rigorous standards for dimensional accuracy, durability, and aesthetic appeal. This final layer of inspection provides the highest level of assurance that every tool shipped is fully compliant with customer requirements.

The Role of Quality Professionals at CDT

The skilled professionals in CDT’s Quality Department bring nearly 150 years of combined experience to this structured approach to quality assurance. Led by Quality Manager Karl Zimmerman, the team is dedicated to upholding the high standards CDT customers expect. "We take pride in inspecting every tool that goes through our shop, across all product lines," Zimmerman says. "Our well-rounded team ensures each product is both appealing and dimensionally precise."

A critical component of CDT’s quality efforts is the final inspection, where Quality Technicians play an essential role. They not only inspect the completed products but also create inspection programs to enhance consistency and efficiency. “As a Quality Tech here at CDT, we use a variety of instruments to ensure tools meet customer specifications precisely,” says former Quality Tech Leslie Gerzinsky.

In this video, Gerzinsky highlights the importance of adaptability and attention to detail in quality control: “Working here requires a willingness to learn and an eye for detail.” This attitude is essential for CDT’s rigorous environment, where every tool is unique and every department is  continuously seeking improvement. “My favorite part of the job is getting to explore different processes and technology. Working in such a supportive, family-like atmosphere really makes the difference,” she adds.

A Quality Culture Built on Continuous Improvement

Quality control at CDT is not limited to final inspections; it is a continual process starting well before production. By working closely with design and production teams, the quality department helps identify and solve potential challenges early, reducing inefficiencies and ensuring a high-quality product. This integrated approach fosters a culture of quality that permeates CDT, from the shop floor to management.

CDT invests in advanced inspection tools and software to maintain a competitive edge in precision and quality. For example, CDT has invested heavily in high-tech measuring equipment from industry leaders like Zoller and Keyence, and our quality techs are skilled in programming this state-of-the-art equipment to streamline quality checks, minimize human error, and enhance team efficiency. Continuous improvement is a guiding principle, driving the team to refine methods and implement new technologies that enhance their inspection and quality control processes. This commitment to improvement enables CDT to stay ahead of industry trends and maintain high customer satisfaction.

CDT’s culture of quality is further reinforced by the dedication of its employees, who take pride in their work and recognize their impact on CDT’s reputation and success. The supportive environment fosters a sense of ownership and collaboration, allowing the quality team to focus on producing reliable, high-performance grinding tools without compromising speed or innovation.

The Key to Customer Satisfaction

At CDT, quality assurance goes hand-in-hand with our dedication to customer satisfaction. Our multi-step inspection process is designed with our customers in mind, to ensure products that are reliable, efficient, and tailored to their needs. This customer-centric approach is key to CDT’s success, underscoring the importance of quality at every step of the process.

With a team of committed professionals and a drive for continuous improvement, CDT ensures that every tool meets the highest standards of precision, durability, and reliability. To learn more about CDT’s quality assurance process or to tour our facility firsthand, reach out to us at www.cdtusa.net/contact. Interested in a career in quality? Check out cdtusa.net/careers for a list of job openings.

Vitrified Bond for High Performance Grinding

When quality and performance are crucial to your industry—whether it’s automotive, aerospace, medical, or electronics—reliable grinding solutions are essential. At Continental Diamond Tool (CDT), we understand these demands, which is why our vitrified bond product line has become a trusted choice for high precision manufacturing worldwide. Today vitrified bond wheels are fast-evolving into one of the most sought-after products in the grinding industry. They stand as a key solution across multiple markets, delivering the high performance and customizability industry leaders need to stay competitive.

Check out this video and article below to explore what makes CDT’s vitrified bond products so effective and why customers across industries trust us to meet their high-performance grinding needs.

The Rapid Growth of CDT’s Vitrified Bond Product Line

Since we introduced this product line in 2014, our vitrified bond grinding wheels have experienced remarkable growth, becoming a cornerstone of our grinding solutions. In just 10 years, our vitrified bond products have gone from being a niche offering to one of the most widely demanded solutions in our portfolio.

Jeff Wirth, Engineering Manager at CDT, reflects on this growth:

“When we first introduced vitrified bonds, we knew they had the potential to meet the demands of a growing number of applications. Today, vitrified bonds have become one of our most popular and successful product lines, offering unmatched results.”

The success of this product line can be attributed to its adaptability, customization, and superior performance, which have allowed CDT to penetrate new markets and expand its presence in existing ones. From high-volume automotive production,rapidly developing semiconductor, or high-stakes aerospace applications, the versatility and reliability of CDT’s vitrified bonds have made them an essential tool for manufacturers around the globe.

Understanding Vitrified Bonds

As Jeff Wirth explains, vitrified bonds are a key element of grinding wheel technology:

“Your bond is basically the glue that holds the materials in your grinding wheel together, and it impacts the wheel's performance. Selecting the right bond for your application is crucial for process efficiency and workpiece quality.”

Vitrified bonds, made from glass or ceramic materials, provide structural integrity and hold the diamond or CBN abrasives together in the wheel. These bonds are valued for their ability to withstand high levels of pressure and heat, making them ideal for challenging grinding operations. Plus, their porous nature allows for the free flow of coolants, reducing the risk of burning and enabling higher material removal rates.

Customizing Solutions for Every Application

One of the major drivers behind vitrified bond’s success is CDT’s expertise in customization. Each wheel is designed to meet the requirements of the customer’s process, ensuring optimal performance for their unique grinding application.

Walt Baumbach, Vitrified Product Manager, explains:

“At CDT, our vitrification process is customized to the specific needs of our customer’s application. Our structures are based on the products our customers are grinding, and we use data-driven analysis to build a structure that is superior to competitors.”

This level of customization enables CDT to craft grinding wheels that maximize efficiency and deliver superior results. From manufacturers of electronic components requiring high-volume precision grinding to medical orthopedics demanding exact tolerances, CDT’s vitrified bond products are tailored to deliver consistent and reliable performance.

The Manufacturing Process of Vitrified Grinding Wheels

At CDT, the vitrified bond manufacturing process is carefully controlled from start to finish to ensure that every product meets the highest standards of quality and performance. Craig Rorick, Production Supervisor for the Vitrified Department, elaborates on the diversity in the industries benefiting from these products: “The industries that use vitrified wheels include automotive, aerospace, medical, and ceramics. Really pretty much every industry—whether directly or indirectly—has vitrified grinding wheels connected to it.”

Here’s a closer look at the exacting manufacturing process:

• Formulation: The process begins with a carefully tailored formulation or recipe, designed to meet each customer's unique grinding application. These formulations include the bond material, abrasive fillers, and other additives used to fine-tune the structure and performance of the grinding wheel.

• Mixing: The dry powders, which consist of glass, ceramic, diamond or CBN, and fillers, are mixed together using a variety of proprietary techniques to create a homogeneous blend.

• Molding: The mixed powder is then carefully poured and packed into the desired mold cavity. This step is crucial for ensuring uniformity and the right density for the wheel's structure.

• Pressing: After molding, the material is pressed to form the wheel’s shape and density, ensuring the bond is strong and capable of handling the demands of high-production environments.

• Sintering/Baking: Pressed wheels are sintered (Baked) at high temperatures in specialized kilns (ovens). This fuses the glass or ceramic bond with the abrasive materials, creating a hard, porous structure that allows for efficient grinding and coolant flow.

• Assembly:  Some wheels require assembly or bonding to metallic or composite components such as threaded wheel studs or cores that allow them to be mounted onto specific grinding machines.  Assembly is done by a proprietary epoxy bonding procedure to ensure product integrity.

• Finishing: Once the wheel has been baked and fused, it undergoes precision machining and grinding to meet the customer's exact size, geometry, and tolerance requirements.

Each of these steps ensures that CDT’s vitrified bond grinding wheels provide superior performance while handling complex grinding tasks.

Key Advantages of Vitrified Bond Grinding Tools

Vitrified bond products from CDT offer several distinct advantages, making them the ideal choice for high-production grinding applications:

High Porosity: Porous Vitrified bonds bring coolant to the grinding zone while allowing grinding swarf and debris to be removed, reducing heat buildup and minimizing the risk of burning the workpiece. This makes them well-suited for high-speed grinding operations.

Lower Grinding Forces: The structure of vitrified bonds reduces grinding forces, which allows for increased grinding speeds and improved efficiency in high-production environments.

Customization: CDT’s vitrified grinding wheels are tailored to each customer’s specific material and application, ensuring superior performance compared to standard off-the-shelf products.

High Tolerance Form Accuracy: Vitrified wheels can be profiled or shaped to meet exacting tolerances, ensuring that they provide consistent form accuracy. This makes them particularly useful for applications requiring complex geometries and precise finishes.

Vit’s Secrets to Market Success

Today, vitrified bond grinding wheels are used in some of the most demanding applications across industries. How have vitrified bond products at CDT become a cornerstone of our business? This success is driven by several key factors:

Versatility: Vitrified bond products have proven to be adaptable across a wide range of industries and applications, from grinding turbine blades in aerospace to shaping medical implants.

Precision and Efficiency: Customers rely on CDT’s vitrified bond wheels to deliver consistent, high-quality results in high-production settings, making them a critical tool in industries where precision and efficiency are paramount.

Continuous Innovation: Over the past decade, CDT has continually refined its vitrified bond technology, expanding its capabilities and offering new solutions to meet evolving industry needs.

Industries Benefiting from CDT Vitrified Bond Products

Vitrified grinding wheels are a vital tool for industries that require both reliability and precision for safety and performance. This advanced technology allows manufacturers to achieve high levels of accuracy, reduce grinding forces, and increase production efficiency with demanding specifications.

How are high-tech industries leveraging this cutting-edge technology?

• Automotive: Commonly used for grinding engine components, such as camshafts and crankshafts, in high-production environments.

• Aerospace: Essential for grinding turbine blades, vanes, shrouds, and other high-precision parts, where exact tolerances are required.

• Medical: A key tool in manufacturing precision surgical instruments and medical implants with critical surface quality considerations.

• Ceramics: Ideal for shaping and finishing hard, brittle materials like ceramics without damaging delicate components.

• Semiconductors: Used in the production of electronic components to maintain quality and functionality in micro-level manufacturing.

Why Choose Vitrified Bond Products from CDT?

At CDT, we are proud of how far our vitrified bond product line has come since 2014. Today, these products are among our most widely used, trusted by industries around the globe. Here’s why customers continue to choose CDT’s vitrified bond:

- Expert Customization: Our experienced engineering team tailors every wheel for optimal performance.

- Attention to Detail: Every step of the manufacturing process is carefully controlled to ensure consistent quality and reliability.

- Reliable Delivery: We understand the importance of timely service, and our customers can trust us to deliver their products when they need them

- Application Support:  CDT has made it a priority to provide our customers with access to experienced Application Engineers to provide support for your specific grinding applications.

With a decade of growth and success, CDT’s vitrified bond product line continues to push the boundaries of grinding technology. If you’re looking for custom grinding wheels, it’s very likely CDT’s vitrified bond products can offer an excellent solution for accuracy, performance, and reliability. Contact us today to learn more about how we can help you achieve your production goals.

CDT Ltd. Unveils £4m Expansion Creating 40 New Jobs

From left: CDT Ltd. Managing Director Jeff Wirth, Finance Manager Michaela Lawton, General Manager Troy Giacherio, Production Manager Justin Hughes, President of Sales Shane Vardaman, and Director Nick Viggiano stand outside the 30,000 sq. ft. factory that the North Wales operation will soon be occupying.

A fast-growing precision engineering firm has announced a £4 million expansion plan that will double the workforce at its North Wales operation by creating 40 new jobs and triple production.

The investment by the American owners of Continental Diamond Tool (CDT) will include moving to a 30,000 sq ft factory that’s nearly three times the size of its current premises in Kinmel Bay and is less than half a mile away on the Tir Llwyd Industrial Estate.

The move is being hailed by staff as the “perfect birthday present” for the North Wales operation which is celebrating its 40th anniversary this year, having been founded as Consort Precision Diamond in 1984, specialising in the manufacture of diamond-encrusted rotary dressers and grinding wheels.

The niche outfit – still one of only two similar companies in the UK – supplies a range of manufacturing sectors, including aerospace, automotive, medical and semi-conductors.

Its products are used in Boeing 777 and 787 Dreamliner aircraft, as well as the Airbus range A330-A380 whose wings are made at the giant Airbus factory in Broughton in Flintshire.

The firm was taken over and rebranded in 2018 by CDT which has its headquarters in New Haven, Indiana.

News of the investment was delivered by company President Nick Viggiano, during his visit to the Kinmel Bay site, along with Shane Vardaman, CDT’s President of Sales.

The bigger factory will enable the company to increase the range of products they make, adding several new types of high precision grinding wheels.

Nick Viggiano said: “Things have worked out even better than I thought and the investment is a real big vote of confidence in the workforce here because they have a similar work ethic  and there’s good camaraderie between everyone.

“We expect to be three times the size we are in a few years’ time because there is a very big market for the products we are going to bring over here.

“We expect a swift ramp-up. Given our extensive expertise with these products in the States, we can help the team over here to quickly hit the ground running.

“The new building is like a blank canvas so we can set everything up exactly the way we want, so we’re very excited about it.”

It was as sentiment endorsed by the American Managing Director, Jeff Wirth, who said: “This investment has been a long time coming, with six years of preparation and teambuilding leading up to this moment.

“Our Kinmel Bay team, known for their rotary dressers, has already started producing electro-plated products on a small scale.

“Moving to the new building that’s nearly three times the size will give us the space to expedite that process. Additionally, we plan to manufacture two vitrified products and a hybrid product in the new space.

“This is a big step and it goes hand in hand with the expansion we’re doing in the United States.

“It comes down to Nick having a belief in the people and the team. This is going to put rocket boosters under the company to continue with the growth trajectory.

“With everything consolidated under one roof, we will get to lay it out to maximise efficiency instead of having to work around the nooks and crannies of the current building.

“The accommodation will also be improved for the employees with nice fresh locker rooms and a cafeteria.

“Nick has a supercharged, can do mentality and we expect to be up and running in the new building in the first quarter of next year.”

According to Finance Manager Michaela Lawton, the Kinmel Bay staff  were delighted to have the opportunity to finally meet Nick and Shane in person.

She said: “We have a solid leadership team here and a fantastic workforce that has the full backing of our American owners and it’s clear that the team here has proved itself worthy of this massive investment.

“It’s going to be a process over the next few years, with recruitment, upskilling and training and a lot of capital expenditure on fitting out the new factory with the specialist equipment that we need.

“We are aiming to follow in the footsteps of our American counterparts who have seen huge growth over the last 10 years.

“They’ve gone from our current size to employing over 200 people and we want to follow the same path.”

Justin Hughes, the production manager in Kinmel Bay, has worked at the Kinmel Bay site for 17 years and is the son of the retired technical director, Peter Hughes, who was among the founders of Consort Precision Diamond.

He said: “The takeover has been a marriage made in business heaven because the operations on both sides of the Atlantic dovetail perfectly with each other.

“The news about the investment is incredibly exciting and is the perfect birthday present as we celebrate our 40th anniversary.

“It will undoubtedly inspire us to reach even greater heights and become a truly global player. The sky really is the limit.”

---

Related articles:

Kinmel Bay firm to double workforce with £4m expansion - Rhyl Journal

Advanced manufacturer Continental Diamond Tool in new larger factory investment creating 40 jobs - MSN

---

An Essential Guide to Grinding Process Optimization for Boosting Performance in Precision Manufacturing

To stay competitive in precision manufacturing, grinding operations require continuous improvement in performance and efficiency. Understanding the factors that influence grinding, such as speeds, feeds, and material removal rates, can significantly impact your results. In this comprehensive guide from Continental Diamond Tool, Product Engineer Thi Dang and Engineering Consultant Jon VanSant share their expertise as they unpack the essential elements of grinding process optimization. Episode 8 of The Grinding Chronicles offers valuable insights into maximizing Q-prime, balancing G ratios, and selecting the right grinding wheel speeds. Whether you’re looking to refine your current operations or upgrade to the latest in bond technology, our engineering team’s breakdown outlines the key factors you need to consider to enhance your grinding processes. Watch the video or read on to discover practical tips and advanced strategies for getting the most out of your grinding tools.

The Grinding Chronicles - Episode 8

Unlocking the Secrets to Optimizing Your Grinding Process

In this article, you will learn the essentials for optimizing your grinding process, focusing on the metrics that matter most for achieving peak performance. From understanding the basics of speeds and feeds to exploring advanced bond technology, this guide provides actionable insights for any precision manufacturing operation. Whether you're new in the field or looking to enhance your current practices, this informative article from The Grinding Chronicles team offers valuable knowledge to help you get ahead in the industry.

Understanding the Basic METRICS in GRINDING

One of the first considerations when optimizing a grinding process is understanding the basics—speeds, feeds, and material removal rates. These elements are fundamental to the grinding process and play a crucial role in determining the efficiency and quality of the finished product.

Speeds and Feeds:

Speeds refer to the rotational speed of the grinding wheel, typically measured in surface feet per minute (SFM). Feeds, on the other hand, relate to the rate at which the workpiece is fed into the grinding wheel. Together, these parameters influence the rate of material removal, surface finish, and the overall efficiency of the grinding process.

It's essential to understand that faster isn't always better. While higher speeds can increase material removal rates, they can also lead to increased wheel wear and the potential for thermal damage to the workpiece. Therefore, finding the optimal balance between speed and feed is key to maintaining both efficiency and quality.

Material Removal Rate (Q-prime):

Q-prime, or material removal rate, is a critical measure of grinding performance. It is calculated by multiplying the depth of cut by the feed rate, resulting in the amount of material removed per unit time. Higher Q-prime values typically indicate shorter cycle times, which can significantly enhance productivity.

However, achieving high Q-prime values requires careful consideration of other factors, such as wheel wear and the quality of the finished surface. A high Q-prime might reduce cycle times, but if it leads to excessive wheel wear or poor surface quality, the overall efficiency of the process may suffer. Thus, optimizing Q-prime involves balancing it with other critical parameters, such as the G ratio.

The G Ratio:

The G ratio is another vital metric in grinding. It is defined as the volume of material removed from the workpiece divided by the volume of wheel wear. A high G ratio indicates efficient grinding, where more material is removed with less wheel wear. However, similar to Q-prime, achieving an optimal G ratio requires balancing various factors.

Maximizing Q-prime WHILE Balancing the G Ratio

Maximizing Q-prime while maintaining a high G ratio is the key to optimizing grinding processes. To achieve this balance, it’s important to consider the following:

1. Wheel Speed: Higher wheel speeds can lead to increased wheel wear due to elevated temperatures. Therefore, it’s crucial to find an optimal speed that maximizes material removal without excessively wearing the grinding wheel.

2. Coolant Delivery: Proper coolant delivery is essential in controlling the temperature during grinding. Efficient coolant systems help dissipate heat, reducing thermal damage to the workpiece and wear on the grinding wheel. This, in turn, helps maintain a high G ratio.

3. Machine Stiffness and Power: The stiffness of the grinding machine and the power of the spindle also play significant roles. Machines with low power or poor stiffness may limit the achievable Q-prime and G ratio, restricting the overall efficiency of the grinding process.

By carefully considering these factors, manufacturers can optimize their grinding operations to achieve both high Q-prime and G ratios, leading to improved productivity and efficiency.

The Evolution of Bond Technology

Bond technology plays a critical role in the performance of grinding wheels, particularly in their ability to achieve high Q-prime and G ratios. The history of bond technology in grinding wheels is a testament to the continuous advancements that have been made in this field.

A Look Back:

In the 1960s, phenolic resin bonds were the standard, offering Q-prime values of around three. By the 1970s, the introduction of polyimide bonds pushed Q-prime values to around five. The year 2000 marked another leap with hybrid bonds, which increased Q-prime to approximately seven.

Today, we are capable of removing material at rates between 10 and 15, thanks to the latest advancements in bond technology. This evolution highlights the importance of continuously upgrading to the latest bond technology to stay competitive in the market.

Introducing CDT's EVO Hybrid Bond:

Continental Diamond Tool has been at the forefront of these advancements with its EVO Hybrid Bond. Released earlier this year, the EVO Hybrid Bond represents a significant step forward in bond technology, offering the ability to achieve Q-prime values over 10 without compromising the G ratio.

The development of the EVO Hybrid Bond was driven by the need for a bond system that could grind aggressively while minimizing wear and maintaining excellent corner retention. This bond was also designed with thermal conductivity in mind, to transfer heat away from the part and prevent damage to the diamond, which is sensitive to high temperatures. Learn more about CDT’s EVO Hybrid Bond product here.

Practical Tips for Optimizing Your Grinding Process

Now that we’ve covered the theoretical aspects of grinding optimization, let’s look at some practical tips that can help you apply this knowledge to your operations:

1. Evaluate Your Current Operations: Start by assessing your current grinding processes. Measure your Q-prime and G ratio to establish a baseline. Identify areas where improvements can be made, whether in speed, feed rate, or wheel selection.

2. Invest in the Latest Technology: Consider upgrading to the latest bond technology, such as CDT’s EVO Hybrid Bond. Newer bonds can significantly improve your material removal rates and reduce wheel wear, leading to better overall efficiency.

3. Optimize Coolant Delivery: Ensure that your coolant system is operating efficiently. Proper coolant delivery is essential for controlling temperatures and reducing thermal damage, which can extend the life of your grinding wheels and improve the quality of your finished products.

4. Regularly Maintain Equipment: Regular maintenance of your grinding machines is crucial. Ensure that your machines are running at optimal stiffness and power to maximize performance and avoid limitations in Q-prime and G ratios.

5. Train Your Team: Make sure your team is trained on the latest grinding techniques and technologies. A well-informed team can make better decisions on the shop floor, leading to improved productivity and efficiency. At Continental Diamond Tool, our application engineers are here to help. We regularly connect with our customers to fine-tune their equipment and train their operators on the optimized speeds and feed rates to use with our grinding wheels.

Optimizing grinding processes is essential for staying competitive in precision manufacturing. By understanding and balancing key factors like Q-prime, G ratio, and wheel speed, manufacturers can significantly enhance their grinding operations. Continental Diamond Tool’s latest advancements, including the EVO Hybrid Bond, provide valuable tools for achieving these goals. Whether you’re looking to improve your current processes or invest in new technologies, the insights provided in this guide offer a clear path to optimizing your grinding operations. Implement these strategies to ensure your manufacturing processes are both efficient and effective, helping you to stay ahead in a demanding industry.

How to Diagnose Surface Pattern Problems in Grinding

Many precision grinding operations require impeccable surface finishes for both function and aesthetics. Addressing surface pattern problems is vital for ensuring the quality of the final product, eliminating waste, and controlling costs. In this detailed overview, we expand on the insights provided by Paul Christy, Senior Product Engineer at Continental Diamond Tool, as he explains how to troubleshoot and fix common causes of surface patterns. In Episode 7 of The Grinding Chronicles, Paul covers the complexities of surface patterns caused by various types of vibrations, runout, and servo system instability. Watch Paul’s video or read on to learn more about identifying and addressing these issues to optimize your grinding operations.

The Grinding Chronicles - Episode 7

Surface Pattern Troubleshooting Guide

Surface pattern problems in grinding can significantly impact the quality and precision of your workpieces. Diagnosing and resolving these issues requires a deep understanding of the underlying causes and appropriate troubleshooting techniques. This article explores common causes of surface patterns in grinding and provides expert insights into their diagnosis and elimination.

Self-Excited Vibration

One of the primary causes of surface pattern problems is self-excited vibration, which occurs at the natural frequency of the machine system. This type of vibration indicates that some component within the machine—such as the spindle, the part, or the dresser—is being excited. The resulting oscillating pattern is called chatter. Notably, this vibration only manifests when the grinding wheel and the workpiece (or the wheel and the dresser) are in contact.

Self-excited vibration results from a lack of sufficient component stiffness. The key to mitigating this issue lies in increasing the machine's stability, which requires a greater machine stiffness compared to the process stiffness. There are three main process variables that can be adjusted to help eliminate self-excited vibration:

1. Velocity of the Workpiece: Lowering the workpiece's speed can reduce process stiffness.

2. Velocity of the Grinding Wheel: Decreasing the grinding wheel's speed similarly lessens process stiffness.

3. Width of Contact: Reducing the contact width between the grinding wheel and the workpiece can also help.

By strategically lowering one or more of these variables, you can effectively diminish the impact of self-excited vibration.

Forced Vibration

Forced vibration occurs at a frequency corresponding to a driving force within or outside the machine. Common examples of such driving forces include unbalanced rotating bodies and pump pulsations. This type of vibration can often be diagnosed using a process of elimination. By sequentially turning on and off all rotating bodies within the machine, you can identify the source of the vibration when it ceases upon the deactivation of a specific component.

Runout

Runout is a prevalent issue in grinding due to the inherent imperfections of rotating components. It occurs when the outer surface of a rotating component does not maintain perfect concentricity with its axis or center line. Specifically, runout in a traversing diamond roll can create a pattern in the grinding wheel, which is then transferred to the workpiece. This pattern typically manifests as angled parallel lines, known as Barber Pole or Roping Patterns.

To address surface patterns caused by runout, it is essential to identify the optimal dresser and wheel RPMs. Varying the diamond roll speed during dressing can reduce the likelihood of pattern formation on the grinding wheel, preventing its transfer to the workpiece. Another effective solution is lapping the diamond roll to the machine's spindle bearings, thereby eliminating runout.

Servo System Instability

Servo system instability is another potential source of surface patterns on workpieces. The servo system controls the movement accuracy of machine components, using digital feedback to ensure precise positioning. Mechanical decoupling within components such as ball nuts, couplings, bearing support units, or scale mountings can create discord within the servo system. This results in oscillations as the system struggles to determine the correct position, leading to surface patterns on the workpiece.

Solving servo system instability typically requires sophisticated instrumentation and physics-based analysis. Iterative process changes alone are unlikely to resolve this complex issue.

Key Takeaways in Mastering Surface Finish

Diagnosing and fixing surface pattern problems in grinding necessitates a thorough understanding of the potential causes and their specific remedies. Whether dealing with self-excited vibration, forced vibration, runout, or servo system instability, targeted adjustments and precise troubleshooting are essential for maintaining the quality and precision of your grinding operations.

For more detailed information and expert guidance, refer to Episode 7 of The Grinding Chronicles, where Paul Christy shows specific measures you can take to diagnose and eliminate surface pattern problems. If you are experiencing surface patterns similar to those discussed in this article and require further assistance, do not hesitate to contact the Continental Diamond Tool engineering team at TheGrindingChronicles@cdtusa.net.

Understanding and addressing these grinding challenges will enhance your operational efficiency and ensure the superior quality of your manufactured products.

CDT Is Boosting Capacity of Plated Grinding Wheels and Dressing Tools

An electroplated grinding wheel completes machining on CDT’s new PUMA DNT 2600LM CNC Lathe.

At Continental Diamond Tool, we invest in cutting-edge technology, skilled professionals, and continuous improvement. We aim to be the world’s most reliable source for innovative, high-quality, customized precision grinding solutions, offering exceptional performance and long life. The market has responded, and the last several years we have experienced tremendous growth.

To meet growing demand, our manufacturing center in North Wales has recently acquired three new pieces of equipment, made possible in part by the Conwy – UK Shared Prosperity Grant. This strategic investment is set to significantly expand our production capabilities for the manufacture of electroplated grinding wheels and diamond rotary dressers.

The Journey of Investment

In Q3 2023, CDT Ltd. in the United Kingdom embarked on an ambitious venture with the introduction of a new product line at its facility: custom-engineered electroplated cBN and diamond grinding wheels and tools. To support this initiative, we purchased dedicated electroplating tanks, stripping lines, and specialized manufacturing equipment for product testing and prototyping. This setup has been essential in ensuring that these products maintain the same precision and quality customers expect from CDT.

Meanwhile, our Rotary Diamond Dressers line — the specialty of this business center — continues to thrive. Sharing machining equipment between this booming line and the growing orders for electroplated products has become a challenge. Additionally, we are starting to see strain in our inspection capacity with the increased demand for these two technologies.

Strategic Acquisitions for Expanding Production

The introduction of a Puma lathe, OGP SmartScope, and Doosan milling machine addresses these challenges and paves the way for sustainable growth, diversification, and more efficient delivery for our customers.

1. Puma DNT 2600LM CNC Lathe

   The first new equipment delivery took place in May with the arrival of the Puma DNT 2600LM CNC Lathe. This piece of equipment is crucial to meet the increasing demand for electroplated products independently from our rotary diamond dressers. Having a dedicated Puma Lathe for plated products assists in the timely delivery of these high-quality tools to our customers without compromise.

2. OGP SmartScope

   In June we received the OGP SmartScope, a revolutionary 3-axis video measurement system. The SmartScope E7, with its IntelliCentric™ fixed lens optical system, 6-megapixel camera, and 5-position digital zoom, delivers high-resolution images that are essential for precise metrology. This state-of-the-art equipment will expand our inspection capacity to maintain the high standards expected of our precision products.

3. Doosan Milling Machine

   Delivered in early September, the Doosan Milling Machine completes our trio of new equipment purchased with the government grant. This addition further bolsters production, ensuring we have the capacity to meet growing demands and continue our commitment to excellence.

A CNC operator programs CDT’s new PUMA Lathe that was delivered and installed in May.

A CDT quality tech measures a coupon on the new OGP SmartScope that was delivered in June.

A technician operates CDT's Doosan Milling Machine that was delivered in September.

Impact and Future Prospects

With the Puma Lathe, OGP SmartScope, and Doosan Milling Machine now up and running, we are already seeing the benefits in our production processes. The ability to utilize these machines for Plated products independently of our Rotary Diamond Dressers line has optimized our workflow and improved our overall efficiency.

These investments also support a long term strategy for CDT Ltd. They not only address our current production challenges but also set the stage for future growth and diversification at this facility. As we continue to innovate and expand our capabilities, we remain committed to the timely delivery of the high-quality products our clients expect.

Stay tuned for more updates as we continue to enhance our production capabilities and explore new horizons in the industry.

---

For more information on the Puma DNT 2600LM CNC Lathe, visit here.

Continental Diamond Tool Ltd., located in Kinmel Bay on the Western Coast of North Wales in the United Kingdom, is dedicated to providing top-tier superabrasive products for precision grinding and dressing.

---

At Continental Diamond Tool, we are excited about these investments and look forward to leveraging this equipment to further our mission of excellence in the industry. If you need a solutions provider for your precision grinding applications, please contact our sales team through our website contact form or
call +44 1745-343951 (UK) / 1-800-443-6629 (USA).

A Breakdown of the 4 Common Bond Systems in High Precision Grinding

If precision grinding is a critical component of your manufacturing process, understanding the bond system of your grinding wheel will help you in maintaining operational efficiency and product quality. In this detailed overview, we will explore the four most common bond systems used in superabrasive grinding wheels: Resin, Metal, Vitrified, and Electroplated. Continental Diamond Tool Engineering Manager Jeff Wirth breaks down the components of these bond systems, discussing their composition, manufacturing processes, and ideal applications in Episode 6 of The Grinding Chronicles. Watch Jeff’s video or read on to learn more about selecting the right bond to optimize your grinding operations.

The Grinding Chronicles - Episode 6

Understanding the Four Common Bond Systems

Resin Bonds

Resin bonds are plastic-based compounds typically made from phenolics or polyimides. These bonds are versatile and can be enhanced with fillers such as copper or silicon carbide to improve performance. The manufacturing process for resin bonds at CDT begins with creating a tailored formulation that includes the bond material, abrasive, and fillers. This dry powder mixture is blended in special tumblers and then carefully and uniformly packed into mold cavities. The molds undergo hot pressing, where temperature and pressure are meticulously controlled to achieve the desired density. Finally, the wheels are finished by machining and grinding them to the specified size and geometry.

Properties and Applications:

• Tough and Durable: Resin bonds are fully dense and easy to use, making them suitable for a variety of grinding applications.

• Versatile: They can work with nearly any material, from hard metals to softer alloys.

• Enhanced Performance: Fillers like copper or silicon carbide can be added to improve heat dissipation and grinding efficiency.

• Wide Range of Applications: Suitable for diverse grinding tasks, including tool and cutter grinding, centerless grinding, and surface grinding.

Metal Bonds

Metal bonds can be composed of various metals, including bronze, copper, and iron, and may sometimes be alloyed with precious metals like silver. Metal bonds are known for their hardness, toughness, and durability, making them ideal for grinding highly abrasive materials such as glass and ceramics. Although metal bonds grind more slowly than other types, they offer the longest lifespan. The manufacturing process for metal bonds at CDT is similar to that of resin bonds, involving formulation, mixing, molding, hot pressing, and finishing.

Properties and Applications:

• Hardest and Toughest: Metal bonds are the most challenging to use but provide superior durability.

• Long-Lasting: They offer the longest lifespan among bond types, reducing the frequency of wheel changes.

• Ideal for Abrasive Materials: Best suited for grinding materials like glass, ceramics, and carbide.

• Durability: Excellent for applications requiring extreme durability and extended wheel life, such as in the automotive and aerospace industries.

Vitrified Bonds

Vitrified bonds are made from glass or ceramic materials, creating a porous structure that significantly reduces grinding force. This allows for higher grinding speeds, making vitrified bonds ideal for high-production applications. These bonds offer moderate to high material removal rates and excellent form accuracy, as they can be dressed and profiled in-process using rotary dressers. The manufacturing process for vitrified wheels at CDT involves formulation, mixing, cold pressing, and a sintering (baking) process to fuse the glass or ceramic together. The final step is finishing, similar to the other bond types.

Properties and Applications:

• Porous Structure: Lowers grinding force and allows increased speeds, enhancing efficiency.

• High Production: Ideal for high-production applications such as automotive part manufacturing.

• Moderate to High Material Removal Rates: Efficient for large-scale operations, balancing speed and precision.

• High Form Accuracy: Can be dressed and profiled in-process using rotary dressers, making them suitable for precise and consistent grinding tasks.

Electroplated Bonds

Electroplated (or plated) bonds consist of a single layer of abrasive held by a nickel-based metal bond. The process begins with machining the desired wheel size and geometry onto a steel wheel core. The non-plated surfaces are masked to prevent unwanted plating. The wheel core is then placed in a bath with a nickel-based solution and the abrasive material. By applying a positive charge on one side and a negative charge on the other, nickel plating is deposited onto the wheel core, causing a single layer of abrasive to adhere. Excess abrasive is removed, and the plating process continues until the abrasive layer is encapsulated to the desired level, typically 50-100% depending on the application. Electroplated products are suitable for complex geometries and low to medium production applications due to their high material removal rates and fast grinding speeds.

Properties and Applications:

• High Material Removal Rates: Provides the fastest grinding speeds, ideal for rapid material removal.

• Cost-Effective: Single layer of abrasive can be stripped and replated, extending the wheel’s life.

• Ideal for Complex Geometries: Precise form replication with minimal finishing, suitable for intricate designs.

• Low to Medium Production: Suitable for specific applications requiring detailed shapes and efficient material removal.

Key Considerations for Selecting the Right Bond System:

Choosing the appropriate bond system for your grinding application is crucial for achieving optimal performance and quality. Each bond type offers unique properties and advantages, making them suitable for different materials and grinding conditions. By understanding the composition, manufacturing processes, and ideal applications of Resin, Metal, Vitrified, and Electroplated bonds, you can make informed decisions to enhance your grinding operations.

Factors in Bond System Selection:

1. Material to be Ground: The hardness and abrasiveness of the material significantly influence the choice of bond.

2. Grinding Speed and Efficiency: Consider whether the application requires high-speed grinding or if longevity and durability are more critical.

3. Application Specifics: Determine if the grinding operation involves complex geometries or requires high form accuracy.

4. Production Volume: High-production environments may benefit from vitrified bonds, while electroplated bonds are ideal for low to medium production with intricate details.

If you have any questions or want to learn more about which bond type would work best for your application, please reach out to our application engineers at TheGrindingChronicles@CDTUSA.net. For more industry insights and expert advice, check out these articles or watch our playlist for The Grinding Chronicles on YouTube. By leveraging the right bond system and understanding its properties, you can significantly improve your grinding efficiency, product quality, and operational cost-effectiveness.

How to Dress a Vitrified CBN Grinding Wheel with a Diamond Rotary Dresser

If you work in manufacturing, particularly in the specialized area of precision grinding, it cannot be overstated the importance of wheel dressing to maintain operational efficiency and product quality. In this comprehensive guide, we will look at the best techniques for traverse dressing a vitrified cubic boron nitride (CBN) wheel using Rotary Diamond Dressers. In Episode 5 of The Grinding Chronicles, CDT Product Manager Troy Giacherio details the specific parameters and most important factors necessary for achieving peak performance in dressing and truing operations. Watch Troy’s video or read on to learn more.

The Grinding Chronicles - Episode 5

Best Techniques for Success When Dressing a Grinding Wheel

Before plunging into the specifics of dressing a Vitrified CBN wheel, it's imperative to understand the dichotomy between two fundamental processes: truing and dressing. Truing involves sculpting the shape or profile of the grinding wheel, while dressing focuses on sharpening the wheel and removing accumulated debris. While diamond rotary dressers serve both functions, understanding this distinction facilitates the implementation of effective dressing strategies.

Essential Parameters for Dressing Success

There are four key parameters to measure for optimizing the dressing of a grinding wheel:

• Velocity Ratio At the heart of dressing lies the velocity ratio, calculated by dividing the velocity of the diamond roll by the velocity of the grinding wheel. This parameter holds significant importance in dressing operations. For Vitrified CBN wheels, the recommended velocity ratio stands at 0.8. Maintaining this ratio ensures that the diamond roll adeptly removes the bond material, laying bare fresh abrasives for optimal grinding performance.

  Overlap Ratio The overlap ratio describes the velocity at which the diamond dresser traverses the wheel's face to sculpt its profile and hone its edge. For Vitrified Bond CBN wheels, an overlap ratio ranging between 2 to 4 is ideal. Sustaining a steady pace ensures a seamless traversal across the grinding wheel. It is important to prevent the dresser from dwelling in any single spot to guarantee uniform dressing proficiency.

  Depth of Dress The depth of dress measures the extent to which the diamond roll plunges into the grinding wheel, thereby dictating the volume of material extracted per pass. When it comes to Vitrified CBN wheels, we recommend a precise depth of dress set at 0.0002 inches per pass. Adherence to this specification not only optimizes grinding efficiency and minimizes downtime, particularly in high-volume production environments, but also preserves the longevity of the grinding wheel, yielding an optimized return on investment.

  Dress Interval The dress interval is defined as the frequency at which the grinding wheel needs dressing, and it is closely tied to the application at hand. Unlike their conventional abrasive counterparts, Vitrified CBN wheels do not require frequent dressing. On the contrary, it is not uncommon to grind hundreds of parts between each dressing session. However, it is important to remain vigilant. Keep an eye on the process and be prepared to adjust the dress interval if part quality diminishes.

When Should I Dress My Grinding Wheel?

Dressing frequency varies depending on several factors specific to your process. Here are two key indicators to monitor in order to assess grinding efficacy and determine when it's time to dress your grinding wheel.

• Power Draw The power draw during grinding operations can be a reliable indicator for grinding wheel dressing. A drop in power draw signals that the wheel is cutting freely, with utmost efficiency, while an uptick in power suggests a looming need for dressing. Neglecting timely dressing can lead to issues such as burn or unwanted variations in surface finish. That’s why it is important to keep a close eye on power draw dynamics to prevent such issues.

• Surface Finish The surface finish of machined parts relies heavily on consistently high levels of grinding performance. A well dressed wheel produces exceptional surface finishes characterized by minimal variations and unyielding consistency in part quality and dimensional accuracy. Therefore, regular dressing sessions conducted with meticulous technique are essential for maintaining superb parts quality and excellence.

Troubleshooting and Optimization

If you are still experiencing issues such as finish patterns or burn despite adhering to prescribed dressing parameters, it may be time to call in the assistance of an expert. Companies like Continental Diamond Tool have application engineers who are trained to analyze grinding processes, pinpoint underlying issues, and facilitate optimization for enhanced performance. Armed with a portable grinding lab, these experts bring their expertise on-site to meticulously evaluate coolant delivery systems, fine-tune machine settings, and traverse a gamut of other variables to resolve persistent challenges. With their help, you can galvanize productivity to unprecedented heights. If you would like help with your wheel dressing or grinding process, don't hesitate to reach out to our engineering team at TheGrindingChronicles@CDTUSA.net.

Mastering Wheel Dressing

Proper dressing of a Vitrified CBN grinding wheel with a Diamond Rotary Dresser is the key to optimal grinding performance and part quality. By incorporating the parameters and techniques we’ve outlined in this article, manufacturers can achieve reductions in downtime, extension of wheel life, and unwavering consistency in high quality results.

Additionally, by closely watching power draw and surface finish, you will know when it is time to dress before problems get out of hand. With consistent dressing, and seeking expert help when needed, companies can overcome grinding challenges and greatly improve productivity.

Whether transitioning from conventional abrasives to CBN or seeking to refine existing grinding processes, mastering proper dressing techniques with Diamond Rotary Dressers holds the key to consistent and dependable success. Check out more grinding related topics in other episodes of The Grinding Chronicles from Continental Diamond Tool.

Conventional Abrasives vs. Superabrasives

In Episode 4 of The Grinding Chronicles, Continental Diamond Tool Engineering Consultant Jon VanSant investigates  the history of common abrasive materials and their key differentiating characteristics that impact wheel life, cutting performance, and efficiency. Using the wrong abrasive for your application can significantly increase your cost per part. Watch Jon’s video or read the article below to learn the differences between conventional abrasives and superabrasives.

The Grinding Chronicles - Episode 4

Understanding Abrasive Evolution

In the early 1800s, precision grinding relied on naturally occurring abrasives like emery. Fast forward to the late 19th century, and we witnessed pivotal developments with the advent of "Carborundum" or silicon-carbide by Dr. Edward Acheson in 1891, followed by the patenting of 'Alundum' or aluminum oxide by Aldus Higgins in 1904. The landscape changed once again with the introduction of synthetic diamond in 1954 and cubic boron nitride (cBN) in 1957, marking the emergence of superabrasives. Although superabrasives were first synthesized in the 1950’s, it took two decades before commercial products became available.

Distinguishing Characteristics

To understand the difference between conventional abrasives and superabrasives, let’s examine three key characteristics: hardness, thermal conductivity, and friability.

• Hardness: An important consideration in abrasive selection, superabrasives like cBN and Diamond demonstrate superior hardness compared to Aluminum Oxide and Silicon Carbide. This is part of what makes superabrasives super, and makes them particularly efficient when grinding extremely hard materials.

• Thermal Conductivity: Enhanced thermal conductivity facilitates efficient heat transfer during grinding operations, ensuring minimal damage to the workpiece. This is critical where surface finish is concerned.

• Friability: Friability reflects the fracture or impact toughness of an abrasive and underscores another crucial aspect. Analysis reveal a substantial disparity between conventional and superabrasives, with the latter exhibiting remarkable compression fracture strength. When comparing the compression fracture strength of diamond and aluminum oxide at a particle size of 400 microns, there is a 10:1 difference between the conventional abrasive and the superabrasive.

Performance Metrics

Moving beyond physical attributes, an examination of performance metrics such as cut, wear, and dressing efficiency further demonstrates superabrasives prowess.

• Cutting Efficiency: Superabrasives like Diamond and cBN require less power and force for cutting operations, ensuring efficient material removal.

• Wear Resistance: Superabrasives demonstrate significantly higher wear resistance, leading to prolonged wheel life and reduced downtime when compared to conventional abrasives.

• Dressing Efficiency: Superabrasives also excel when considering downtime for dressing since they maintain dressing efficiency over extended periods. In some cases, we have seen up to 20 times the parts per dress. With less frequent dressing comes more consistent performance. Plus, you’re only taking off a tenth of the material in dressing, so your wheel lasts much longer.

Cost Considerations

Superabrasives, with their many advantages, do come with a substantial up-front investment. Even so, many companies see sustainable returns.

• Long-Term Value: Superabrasives offer enhanced productivity and cost-effectiveness that often results in lower cost per part over time.

• Application Considerations: Recognizing that not every application warrants a superabrasive grinding wheel, factors such as machine tools, fluid compatibility, and work volume must be considered. Superabrasives are most cost effective in high volume, extremely demanding applications.

Expert Guidance

Thank you for joining us on this exploration of grinding wheel abrasives. If you would like help deciding which abrasive would work best to optimize your grinding process, don't hesitate to reach out to our engineering team at TheGrindingChronicles@CDTUSA.net. Until next time, check out additional insights and discoveries on other episodes of The Grinding Chronicles.

Understanding the Distinction Between CBN and Aluminum Oxide Abrasives

Are you ready to explore the fascinating world of abrasives? In manufacturing, we often encounter Superabrasives and Conventional abrasives. In the Superabrasives corner, we have Diamond and Cubic Boron Nitride (CBN), and their common Conventional abrasive counterparts are Silicon Carbide and Aluminum Oxide. Each serves a specific purpose. What makes CBN and Aluminum Oxide stand out is their exceptional ability to tackle those stubborn steels and metals that can't stand Carbon.

In this blog, we'll explore the properties and applications of CBN and Aluminum Oxide abrasives. Discovering their unique characteristics will help you choose the right abrasive for your specific machining needs, ensuring efficiency and top-notch results. Whether you're working with hardened steels or softer metals, the right abrasive is the key to achieving your desired outcome in grinding and machining. So, let's dive in and unlock the true potential of CBN and Aluminum Oxide abrasives.

What is CBN?

CBN is a synthetic Superabrasive known for its incredible hardness, high thermal conductivity, and thermal stability. Originally released with the trade name Borazon from GE Superabrasives, its cubic crystal lattice structure is similar to Diamond, giving it remarkable abrasive properties. With a hardness close to 10 on the Mohs scale, CBN excels in machining tough materials that require precision grinding. Its chemical composition and high thermal stability prevents chemical reactions and premature breakdown under high temperatures, when grinding ferrous metals and high-temperature alloys. What's more, because CBN doesn't react with ferrous materials, it doesn’t alter or change their properties resulting in longer life in use when ground with CBN.

CBN is a game-changer when grinding hardened ferrous alloys or super alloys that are sensitive to heat. It efficiently grinds hardened steels while maintaining accuracy and surface finish. Plus, it's a favorite for grinding ferrous metals like cast iron and stainless steel, ensuring clean and precise results without chemical alterations. CBN is a must-have tool for achieving precise and efficient outcomes in critical machining tasks.

What is Aluminum Oxide?

Aluminum Oxide, also known as alumina, is a versatile Conventional abrasive. With high hardness and toughness, it is available in various grit sizes, making it perfect for a wide range of machining and finishing applications. Though not as hard as CBN, Aluminum Oxide is fantastic for soft metals, wood, and non-ferrous materials. While it may not match the precision of Superabrasives, it's still a reliable choice for many tasks.

In the machining industry, Aluminum Oxide is the go-to for grinding soft metals like aluminum, brass, and copper. It performs beautifully with non-ferrous materials such as bronze and titanium, without causing any chemical interactions. Its role in achieving desired surface finishes across various industries, from automotive to aerospace, is unparalleled.

Key Differences Between CBN and Aluminum Oxide Abrasives

While CBN and Aluminum Oxide both play significant roles in grinding and machining operations, they have many distinct properties that set them apart.

Crystal Structure and Hardness: CBN's crystal lattice structure is similar to Diamond, resulting in exceptional hardness and wear resistance. Aluminum Oxide, while still hard, has a lower hardness than CBN, making it more suitable for soft metals and certain alloys.

Heat Resistance and Thermal Conductivity: CBN exhibits superior heat resistance and thermal conductivity compared to Aluminum Oxide, making it perfect for grinding high hardness and heat sensitive alloys.

Material Compatibility and Reactivity: Both CBN and Aluminum Oxide are chemically inert with ferrous materials whereas Diamond and Silicon Carbide are not, thus why they are the abrasives for ferrous metals.

Cost and Practicality: CBN grain costs significantly more than Aluminum Oxide grain, resulting in higher grinding wheel prices. Because of higher hardness and better thermal conductivity, CBN wheels can provide lower grinding costs in applications where high workpiece hardness and thermal properties need to be maintained. In cases of grinding soft steels and low volume production, the lower wheel price of Aluminum Oxide makes it a more competitive option.

Safety Considerations and Handling

Whether you choose CBN, Aluminum Oxide, or another solution for your abrasive, ensuring safety during grinding and finishing processes is essential. Proper machine guarding, eye and respiratory protection, proper dust/mist extraction, and careful handling and storage of abrasives are crucial to protect workers and maintain a clean and safe work environment.

Selecting the Right Abrasive for Specific Applications

Choosing the right abrasive for your specific machining needs is vital to achieving optimal results. Making an informed decision will ensure efficient, accurate, and cost-effective grinding and finishing processes. Some factors to consider include:

Workpiece Material Characteristics: Soft metals like aluminum, brass, copper, and mild steels  may need moderate hardness abrasives like Aluminum Oxide to prevent excessive material removal, while harder materials like hardened steels and high-temperature alloys such as inconel and hardened Stainless Steel  require abrasives with superior hardness and high thermal conductivity like CBN for precise and efficient cutting and grinding.

Machining Operations and Efficiency: Superabrasives like CBN are preferred for high-precision tasks where tight tolerances and maintaining material properties are paramount, while conventional abrasives like Aluminum Oxide offer lower cost solutions for general grinding of mild steel and soft metals.

Surface Finish and Material Removal Rates: Superabrasives like CBN excel in production applications of hardened steels and Superalloys that are sensitive to heat, , while conventional abrasives like Aluminum Oxide are effective in low volume applications and for grinding of soft metals.

Tooling and Machinery Considerations: Abrasive selection also needs to account for machinery and tooling capabilities.  The truing and dressing of Superabrasive and Conventional Abrasive grinding wheels can be different and require different tools (stationary or rotary dressers of different configurations).  Because of the difference in hardness between CBN and Alumina, Alumina being much lower, the amount of grinding debris resulting from wheel wear during grinding can be 100-300 x’s greater with the conventional wheel, which in turn needs to be disposed of.  .

Both CBN and Aluminum Oxide abrasives offer distinct advantages in grinding and machining. Considering their unique properties with specific application requirements will lead to efficient and precise processes, ensuring optimal results and safety in the workplace. And if you ever need assistance, our grinding experts at CDT are here to help. Whether it's Superabrasives or Conventional abrasives, we can help find the perfect solution for your process.
