Workpiece: Ø3/4”, 3 flute end mill, 40˚ helix Machine: ANCA MX7 Coolant: Oil
CDT Hybrid Fluting Wheel
Specifications: 1B1R 5 x 1/2 x 1-1/4 D320-HE-28-MK 3/8 PC V=15
*Vs. Competition’s D91 Hybrid Wheel
Fluting Cycle Reduced by 80%*
Fluting was originally done in 2 passes. The CDT Resin Hybrid Bond achieved a single pass at double the feed rate with no damage to the workpiece, while achieving a 25% increase in finish.
Primary and Secondary Grind for the Cutting Tool Industry
Workpiece: Ø1/2”, 3 flute end mill, 40˚ helix Machine: ANCA MX7 Coolant: Oil
CDT Hybrid 11V9 Wheel
Specifications: 11V9 3-3/4 x 1-1/2 x 1-1/4 D320-QE-28-MK 1/8 PA
*Vs. Competition’s D64 Hybrid Wheel
Primary and Secondary Cycle Reduced by 70%*
The Resin Hybrid Bond increased the primary and secondary operations by 4 times while continuing to produce a better finish.
